Quartz Cuvette Optical Glass Cuvette Spectrophotometer Cuvette Manufacturer
Detailed Diagram
High Precision Cuvettes for UV-Vis and Fluorescence Spectroscopy
XKH supplies high-quality Quartz Cuvettes, Optical Glass Cuvettes, and Disposable Plastic Cuvettes for UV-Vis spectrophotometers, fluorescence spectrometers, colorimeters, and analytical instruments. Manufactured with precision optical polishing technology, our cuvettes offer excellent optical transmission, accurate optical path length, and superior chemical resistance, ensuring reliable and repeatable measurement results.
From routine laboratory analysis to advanced scientific research, our cuvettes are widely used in biotechnology, pharmaceutical testing, environmental monitoring, food safety, semiconductor chemical analysis, and academic research laboratories worldwide.
Key Features of Quartz Glass Sheets
- Excellent optical transmission with low light scattering
- High-precision optical path length (±0.01 mm available)
- UV-grade synthetic fused silica for deep UV applications
- High scratch resistance and polished optical windows
- Excellent resistance to acids, alkalis, and most organic solvents
- Available in quartz, optical glass, PMMA, and PS materials
- Standard, semi-micro, micro-volume, flow-through, and fluorescence cuvettes
- OEM & custom manufacturing available
Available Materials
Quartz Cuvette
Quartz cuvettes provide outstanding UV transmission from 190–2500 nm, making them ideal for UV-Vis spectroscopy, fluorescence analysis, DNA/RNA quantification, and protein concentration measurements.
Advantages
- UV to Near-IR transmission
- Excellent thermal stability
- Superior chemical resistance
- Reusable with long service life
Technical Specifications
| Parameter | Specification |
|---|---|
| Materials | Quartz, Optical Glass, PMMA, PS |
| Optical Path Length | 1 mm, 2 mm, 5 mm, 10 mm, 20 mm, 50 mm or Customized |
| Wavelength Range | Quartz: 190–2500 nm |
| Visible Glass | 340–2500 nm |
| Plastic (PS/PMMA) | 300/340–900 nm |
| Window Type | Two Optical Windows or Four Optical Windows |
| Capacity | Standard & Micro Volume |
| Surface Finish | Precision Optical Polishing |
| Custom Service | Available |
Applications
Our optical cuvettes are widely used in:
- UV-Vis Spectroscopy
- Fluorescence Spectroscopy
- DNA & RNA Analysis
- Protein Quantification
- Chemical Analysis
- Water Quality Monitoring
- Pharmaceutical Testing
- Food Safety Inspection
- Environmental Monitoring
- Semiconductor Chemical Analysis
- University & Research Laboratories
Frequently Asked Questions
What is the difference between quartz and glass cuvettes?
Quartz cuvettes transmit ultraviolet light from approximately 190 nm and are suitable for UV-Vis applications. Glass cuvettes are intended for visible-light measurements and cannot be used for deep-UV analysis.
What is the standard optical path length?
The industry standard is 10 mm, while shorter or longer path lengths such as 1 mm, 2 mm, 5 mm, 20 mm, and 50 mm are also available.
Can you manufacture custom cuvettes?
Yes. We provide OEM and custom manufacturing services for dimensions, materials, optical path lengths, window configurations, and special designs.
About Us
XKH specializes in high-tech development, production, and sales of special optical glass and new crystal materials. Our products serve optical electronics, consumer electronics, and the military. We offer Sapphire optical components, mobile phone lens covers, Ceramics, LT, Silicon Carbide SIC, Quartz, and semiconductor crystal wafers. With skilled expertise and cutting-edge equipment, we excel in non-standard product processing, aiming to be a leading optoelectronic materials high-tech enterprise.
